MaceTouch Screen

Interactive Panel Multitouch 4K Smart board

MaceTouch smart board provides all in one design and functions, integrate touch screen, PC Sytem and Smart TV in one.

All in one touch function with mobile stand, easily used for kindergarten fun teaching, or small meeting room(< 15 ㎡).

*Anti-Glare Surface ,Tempered Glass provides kind protection for eyes, or kids interactive writing- afterclass activities.

*Dual Colors Pen get writing with 2 colors , easier and no need select again.



MaceTouch smart board 6 in one : Smart TV, PC, Porjector,Projector Screen, Speaker,whiteboard.

4K UHD Pixel for High quality Pictures or Videos.

Digital writing with automatic saving , QR code scanning -takeaway.

Spliting screen 2-3 screens for Multi users particiate.

Different Themes including Education, Conference, Medical and Etc.

Wireless Screen-Share for IPhone, Macbook, and Laptop.

Screen -Lock available for teachers or Conference host.

Files Fast Tranfering will be much helpful to record meeting contents.

Android 13.0 4+32GB runs smoothly , and faster.

Windows OS Options. Mobile Stand Options, Silver and Black color options

*Panel Features * Touch Parameters
Screen Size 55 65 75 85 86 98inch Touch Sensing Technology Infrared Sensor – 20 Points
Active Display Area 1209.6(H) x 680.4(V)(mm) Writing Method Pen Finger & Etc
Pixel Pitch (mm) 0.63 (W) x 0.63(H)(mm) Positioning Accuracy ±1.5mm
Native Resolution 3840*2160 RGB Touch resolution 4096X4096
Aspect Ratio 16:09 Communication Interface USB
Brightness (Type) 350 Nits Touch Times Unlimited Theory
Contrast Ratio (Type) 5000 Computer Response ≤12ms  Auto
Viewing Angle 178(H)/178(V) Transfer Speed 125P/S
Response Time Max 8ms Driver HID Free
Display Color 8 bit/16.7M *Computer Setup(OPS)Options
Frame Rate 60 Hz OS system Win10
Backlight LED Chipset (CPU) Intel 5, 4th Gen
Life Time >50000 hours RAM 8GB
*Android OS SSD 256 GB
OS system Android 14.0 Decoding Resolution 3840*2160
Chipset (CPU) V100 Version;

Octa core ARM Cortex-A55

Mali-G52 MP2 (2EE)

Graphics Card Integrated Graphics
Sound Card Integrated
RAM 4 GB/8GB Driver Latest Updated
Flash 32 GB/128GB Networking Support Ethernet, Wi-Fi,5G
Color Format PAL/NTSC/SECAM Language English
Sound Format BG /DK /I Program Integrity Standards Yes
Decoding avi.mp4.ts/.mkv/mov.mpg.dat.vob.

rmvb.m4a/aac.jpg/jpeg.bmp.png.txt

* Materials
Surface Anti-Glare Surface
tempered glass
OS Update USB Update Frame Aluminum Alloy Metal
OSD Language Multi Languages -English Back Cover Metal
* Input Connectivity * Output Ports
AV IN/Out *1 Earphone *1
HDMI IN *1 Coaxial *1
VGA IN *1 *Audio Feature
LAN/RJ45 *1 Audio Frequency output Two Speaker 15W*2
USB IN *4 *Power Features
TF *1 Power Supply 100V-240V,50-60 Hz
DP *1 Power Standby ≤1W
RS232 IN *1 Power Consumption( Watt) ≤100W
YPBPR IN *1 OPS Consumption(Watt) Options
* Mechanical Design *Stand Accessories
Chassis Colors Black / Sliver WIFI Antenma 1
Tempered Glass 4 mm Remote Control 1
Curvature Design No Power Cord 1
VESA Wall Mount Yes (500*400mm) Warranty Card 1
Front Control (key) Power User Manual 1
Front Interfaces USB*2 Touch Pen 1
Front Siganl Light 1 Wall Bracket 1



Weight 38 kg
Dimensions 125 × 7.4 × 8.4 cm
Panel

BOE LG Original A Grade

Size

55/65/75/85/86/98 inch

Touch

Infrared touch 20 Points Touch (40 pts Option);
Zero-Bonding IR touch Options

Camera

Optional 12/48M Pixel Camera and Mic

Warranty

18 Months
