Interactive Virtual Flipbook TouchScreen Totem Kiosk Display

Size: 43/49/55 inch
Applications: Library, museum, large shopping plaza, exhibition hall, BANK, HOTEL etc.
Functions: Interactive query, infrared sensor, electronic flip book.

Speficications  丨MAC43K
*Panel Features * Touch Parameters
Screen Size 43″ Touch Sensing Technology Infrared Sensor – 10 Points
Active Display Area 943*531mm Writing Method Pen Finger & Etc
Native Resolution 1920*1080 RGB   ( 2K ) Touch resolution 4096X4096
Aspect Ratio 16:09 Communication Interface USB
Brightness (Type) 350 Nits Touch Times Unlimited Theory
Contrast Ratio (Type) 5000 Computer Response ≤8ms  Auto
Viewing Angle 178(H)/178(V) Transfer Speed 125P/S
Response Time Max 8ms Driver HID Free
Display Color 8 bit/16.7M *working
Frame Rate 60 Hz Working temperature below zero 20 to 65 ℃
Backlight LED Storage temperature below zero 30 to 75 ℃
Life Time >50000 hours Audio Frequency output Two Speaker 10W*2
*windows OS Power Supply 100V-240V,50-60 Hz
OS system Win10 *Stand Accessories
Chipset (CPU) Intel 5/7 WIFI Antenma 1
RAM 4 / 8 GB Power Cord 1
ROM 128/256 GB SSD Warranty Card 1
Graphics integrared User Manual 1
Networks WIFI & LAN 2.4G/5G Touch Pen 1
Language English Wall Bracket 1
* Input Connectivity of windows *Software
USB IN *4 PC softwares Chorme
HDMI OUT *1 Flip book software yes
VGA IN *1 Air Sensing software yes
LAN/RJ45 *1 Materials
input of touchscreen Tempered Glass 3 mm
USB IN *1 Curvature Design No
* Mechanical Design Glass Surface Tempered Glass
Chassis Colors White Sensors 2 sensors on front
